Electro Voice ETX-35P

• 15-inch LF SMX woofer
• 6.5-inch MF driver
• 1.25-inch HF titanium compression driver
• 2000 W Class-D power amplifier with integrated FIR-Drive DSP
• 136 dB peak SPL

Frequency Range    38 Hz 20 kHz
Maximum SPL    136 peak dB
Power Consumption    100 240 V~, 50 60 Hz, 1.6 0.8 A
Power Rating    2000 W
Frequency Response    48 Hz 20 kHz
Coverage (Nominal -6 dB) H    60 °
Coverage (Nominal -6 dB) V    40 °
LF Transducer    SMX2151 380 mm (15 in)
MF Transducer    EVS-6C 6.5-in midbass driver
HF Transducer    DH3-B 1.25-in titanium compression driver
Crossover Frequency    700 Hz, 2900 Hz
Connector Type    (2) XLR/TRS combo jack and (1) XLR link output
Enclosure Material    18-mm, 13-ply birch plywood with EVCoat
Grill    16AWG steel with powdercoat
Suspension    (8) M10 suspension points
Height    1023 mm
Width    469 mm
Depth    426 mm
Weight Net    41.7 kg
Shipping Weight    46.8 kg
